Subaru STI Turbo Blanket


Funk Motorsport Turbo Blankets are made from the highest quality materials and are available for all turbo applications in both Carbon Fibre and Titanium Lava Rock..

In stock (Ready To Ship)


The Funk Motorsport Subaru STI Turbo Blanket is made from the highest quality materials and are available for all turbo applications. This Turbo Blanket is specific to the Subaru engine featured on the STI. This blanket is specific to the Subaru STI turbo. This turbo jacket has been produced to accommodate the complex shape of the TD04 / TD05 STI turbo. Usually found on 2002-2013 Subaru Models. Will fit models vf22 vf34, vf48, 16g, 18g

Due to the close proximity between the two halves of the turbo, it is extremely common for heat sink to occur. This can decrease performance output while increasing the work of the input components during the combustion cycle. Funk Motorsport Turbo blankets are designed to keep the hot side of your turbo insulated while keeping the cold side at optimum temperatures. This helps to provide cooler airflow to the cooling system and MAF sensor, leading to an increased ignition spark and higher output of energy from combustion. By ensuring that the turbine sector of the turbo remains hot, less heat will be dissipated into the engine bay, ensuring that exhaust gases will flow with less turbulence from the exhaust. See this in action in our video section!

Why is heat management so important? Find out here.

Additional information

Weight0.5 kg

Additional Info

Note of caution:
This turbo blanket is not flammable. However if any flammable fluids are introduced into close proximity of the blanket, the blanket could become a suitable ignition source for a flame to be produced. Please ensure that all necessary precautions are taken in regards to the appropriate maintenance of all oil and fuel lines and fittings surrounding the turbo charging and fuel injection system. Funk Motorsport take no responsibility for fluid contamination our products.

Whilst this heat shield is removable after fitment, it is not designed to be removed once a number of heat cycles has been introduced into the product. After the blankets have been heated they will lose some of their internal construction properties, though we must stress that this does not reduce any thermal properties of the product.

Interior Surface:
Max Temperature Rating: 1260 Deg C
Continuous Use Limit: 1000 Deg C

Exterior Surface (Titanium)
Direct Contact Limit: 982 Deg C
Radiant Heat Limit: 1371 Deg C
